Product name |
Heavy Duty Sleeving made of High-density polyethylene (HDPE) |
|
Material |
PP |
|
Producing way |
Extrusion |
|
Hardness |
85A-90A |
|
Temperature resistance |
-40°C-120°C |
|
Tensile Strength |
25MPa at normal temperature, 30MPa at -40 °C |
|
Impact Strength |
35KJ/sqm at normal temperature, 5KJ/sqm at -40 °C |
|
Inner diameter |
8mm-200mm |
|
Outer diameter |
10mm-300mm |
|
Shape |
convex surface and flat surface |
|
Color |
any color |
|
Application |
Mainly installed in the hydraulic hose, wire and cable products external. |
|
Craft: |
Best Vulcanization and Microwave courting |
|
Packaging |
(1) 2 meters/root discharge a layer and two layers are separated by the thin cardboard in a carton (200*40*20mm). (2) Length per customer's requirement in one roll. (3) According to customer requirements. |
Specification:
| Part Number | Size (ID) | Wall Thickness(mm) | Width(mm) | Bundle Diameter Range(mm) | |
| mm | inch | ||||
| SW-08 | 8 | 5/16" | 1.1 | 7.0 | 8-12 |
| SW-10 | 10 | 3/8" | 1.1 | 10.0 | 9-11 |
| SW-12 | 12 | 1/2" | 1.1 | 12.0 | 11-14 |
| SW-14 | 14 | 11/20" | 1.5 | 13.0 | 13-16 |
| SW-16 | 16 | 5/8" | 1.5 | 15.5 | 15-18 |
| SW-18 | 18 | 3/4" | 1.8 | 16.0 | 17-20 |
| SW-20 | 20 | 4/5" | 1.8 | 16.0 | 19-22 |
| SW-22 | 22 | 43/50" | 2.0 | 19.5 | 20-26 |
| SW-25 | 25 | 1" | 2.0 | 22.5 | 25-29 |
| SW-28 | 28 | 1-1/10" | 2.0 | 23.0 | 28-32 |
| SW-30 | 30 | 1-9/50" | 2.0 | 23.0 | 30-35 |
| SW-32 | 32 | 1-1/4" | 2.2 | 23.5 | 32-38 |
| SW-35 | 35 | 1-19/50" | 2.2 | 24.0 | 35-40 |
| SW-38 | 38 | 1-1/2" | 2.5 | 28.0 | 38-40 |
| SW-40 | 40 | 1-29/50" | 2.5 | 28.0 | 39-42 |
| SW-42 | 42 | 1-13/20" | 2.5 | 28.0 | 42-49 |
| SW-45 | 45 | 1-39/50" | 3.0 | 28.0 | 45-52 |
| SW-50 | 50 | 2" | 3.0 | 28.0 | 50-60 |
| SW-60 | 60 | 2-1/2" | 3.0 | 28.0 | 60-74 |
| SW-74 | 74 | 2-9/10" | 4.0 | 46.5 | 70-85 |
| SW-80 | 80 | 3-3/20" | 4.5 | 48.5 | 80-85 |
| SW-88 | 88 | 3-1/2" | 4.5 | 50.0 | 85-98 |
| SW-100 | 100 | 4" | 4.5 | 57.0 | 95-135 |
| SW-130 | 130 | 5" | 4.5 | 50.0 | 130-155 |
| SW-150 | 150 | 6" | 5.0 | 50.0 | 150-175 |
