Specification
| Item NO. | inner diameter D(mm) |
outer diameter D1(mm) |
screw pitch W(mm) |
Wrapping Range (mm) |
Packing |
| SW-3 | 1.5 | 3 | 4 | 1.5*10 | 10m |
| SW-4 | 2.5 | 4 | 4.5 | 2*20 | |
| SW-6 | 4 | 6 | 7 | 4*50 | |
| SW-8 | 6 | 8 | 10.8 | 6*60 | |
| SW-10 | 7.5 | 10 | 11.4 | 7.5*60 | |
| SW-12 | 9 | 12 | 13.9 | 9*65 | |
| SW-14 | 11 | 14 | 14.5 | 12.5*60 | |
| SW-15 | 12 | 15 | 15 | 12*75 | |
| SW-16 | 13 | 16 | 16 | 13*85 | |
| SW-18 | 14 | 18 | 17 | 14*90 | |
| SW-19 | 15 | 19 | 18.2 | 15*100 | |
| SW-20 | 17 | 20 | 18.5 | 16*105 | |
| SW-22 | 18 | 22 | 19 | 18*110 | |
| SW-24 | 20 | 24 | 19.6 | 20*130 | |
| SW-26 | 22 | 26 | 20 | 22*135 | |
| SW-28 | 24 | 28 | 28 | 24*140 | |
| SW-30 | 26 | 30 | 43 | 26*150 |
